AVDEL
Avseal Sealing Plug (Low Pressure)
2964
Avseal blind sealing plugs are unique in the efficient sealing performance provided in both low- and high-pressure hole sealing applications. This rapidly installed two-piece sealing plug improves quality and safety in demanding applications while simplifying hole preparation and installation, reducing assembly costs. Typical applications include engine blocks, transmissions, cylinders, brakes, gear box, pneumatic systems, hydraulic blocks, compressors, and pumps.
- Series: Low pressure
- Sleeve material: Aluminium
- Stem material: Steel
- Sizes: 9.0 mm - 16.0 mm
| Part No. | Size ⌀ | CAD | Quantity | |
| 02964-00911 | 9.0 | - |
|
|
| 02964-01012 | 10.0 | - |
|
|
| 02964-01113 | 11.0 | - |
|
|
| 02964-01215 | 12.0 | - |
|
|
| 02964-01315 | 13.0 | - |
|
|
| 02964-01415 | 14.0 | - |
|
|
| 02964-01620 | 16.0 | - |
|
