SOUTHCO
Push-To-Close Actuator
E5
Push-to-close cam style rotates freely from the "closed" position as it contacts the frame or keeper; an integral spring pushes cam back into the engaged position once cam clears the keeper.
- Single hole installation
- Latched/unlatched status indicator provides user with quick visual confirmation of latch status
| Part No. | Type | Finish | Rotation | Lock Style | Key Options | CAD | Quantity | |
| E5-5-405-510-13 | Cylinder Lock | Black Powder Coated | Type A (Single Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-5-405-TL0-13 | Cylinder Lock | Black Powder Coated | Type B (Two Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-5-405-TR0-13 | Cylinder Lock | Black Powder Coated | Type A (Two Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-9-305-510 | Wing | Black Powder Coated | Type A (Single Point) | Non Locking | - | Download |
|
|
| E5-9-305-TR0 | Wing | Black Powder Coated | Type A (Two Point) | Non Locking | - | Download |
|
|
| E5-9-315-510-13 | Wing | Black Powder Coated | Type A (Single Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-9-315-TR0-13 | Wing | Black Powder Coated | Type A (Two Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-9-335-510 | Wing | Black Powder Coated | Type A (Single Point) | Without Lock Core | - | Download |
|
|
| E5-9-335-TR0 | Wing | Black Powder Coated | Type A (Two Point) | Without Lock Core | - | Download |
|
|
| E5-9-605-510 | T-Handle | Black Powder Coated | Type A (Single Point) | Non Locking | - | Download |
|
|
| E5-9-605-TR0 | T-Handle | Black Powder Coated | Type A (Two Point) | Non Locking | - | Download |
|
|
| E5-9-615-510-13 | T-Handle | Black Powder Coated | Type A (Single Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-9-625-510-13 | T-Handle | Black Powder Coated | Type A (Single Point) | Locking (R001) | Key Supplied | Download |
|
|
| E5-9-635-510 | T-Handle | Black Powder Coated | Type A (Single Point) | Without Lock Core | - | Download |
|
|
| E5-9-705-510 | L-Handle | Black Powder Coated | Type A (Single Point) | Non Locking | - | Download |
|
|
| E5-9-715-510-13 | L-Handle | Black Powder Coated | Type A (Single Point) | Locking (CH 751) | Key Supplied | Download |
|
|
| E5-9-735-510 | L-Handle | Black Powder Coated | Type A (Single Point) | Without Lock Core | - | Download |
|
